GTP80A
9HP Portable Gasoline Water Pump for Medium Tasks
- Strong Power Output: Provides a flow rate >400 L/min with a head of 10-30m. The 270cc engine delivers stable 9 HP at 3600 RPM, balancing efficiency and cost-effectiveness.
- High Self-Priming Capability: With an 8m maximum suction head and 80mm discharge port, it offers excellent water source adaptability, ensuring stable water supply even in low-water-level scenarios.
- Universal Compatibility: The gasoline-driven, air-cooled design with a semi-open impeller supports multiple applications including clean water transfer, irrigation, and circulating water systems.
- High Loading Efficiency: 111 units can be loaded in a 20ft container, with a 45-day lead time. Strong annual production capacity delivers significant cost advantages for bulk purchases.
- Compact & Reliable: The horizontal medium-pressure structure features a compact design for easy installation. Manufactured in Fujian, China, it guarantees stable quality and long-term durability.
PRODUCT DESCRIPTION
Standard Description UNITED POWER GTP80A is an efficient gasoline-driven centrifugal pump that balances high flow with cost-effectiveness, ideal for medium-sized water transfer applications. Powered by a 270cc Up177 gasoline engine, it outputs 9 HP at 3600 RPM, delivering a flow rate of over 400 L/min with a head range of 10-30m. The 8m maximum suction head paired with an 80mm discharge port ensures excellent water source adaptability, enabling efficient water supply even from low-level sources. Featuring a single-stage, single-suction semi-open impeller and horizontal medium-pressure structure, along with an air-cooled system, it supports long-duration outdoor operations. Widely used for agricultural irrigation, garden water supply, small construction site drainage, and clean water circulation. Its compact size allows for easy installation. Packaged in cartons, 111 units can be loaded per 20ft container. With a robust annual production capacity and 45-day stable delivery from our Fujian factory, it undergoes strict quality control, offering an ideal balance of performance and value for medium-sized water transfer projects.
SPECIFICATIONS
| Model | GTP80A |
| Discharge Port Dia(mm) | 80(3in) |
| Rated Capacity(m3/h) | 65 |
| Self-Priming Time(s/4m) | 55 |
| Max. Head(m) | 26 |
| Max. Suction Head(m) | 8 |
| Dimension (L×W×H) (mm) | 672*515*625 |
| Net weight/Gross weight(KG) | 53/58.5 |
| 40ft container Qty | 222 |
| Engine | 270cc/UP177 |
| Engine Type | Single-Cylinder, 4-Stroke, Air-Cooled; OHC Gasoline Engine |
| Displacement Capacity(CC) | 270 |
| Max. Output（HP/rpm) | 9.0/3600 |
| Fuel Tank Capacity(L) | 6.5 |
INCLUDES
(1x) Spark plug wrench
(1x) Owner’s manual
Please provide the model type of your machine in your inquiry, and mention the keywords like chainsaw parts, brush cutter parts, sprayer/mist duster parts, leaf blower parts, hedge trimmer parts, water pump parts, generator parts, engine parts, lawn mower parts, etc.
