UP194
7000/7500W open-frame inverter generator
LEARN MOREYou don’t need a “home backup” generator that whispers. You need one that delivers – and still lets you sleep. Meet the United Power 8KW openframe inverter generator: a portable power plant for people who actually use their tools.
Why 8KW?
Because 5000 watts runs your fridge and a few lights. 8000 peak watts runs your well pump, your table saw, your garage heater, and your neighbor’s desperation all at once. This machine is built for the moment when “enough” isn’t enough.
Real inverter technology, real output
Most openframe generators this size are oldschool synchronous – loud, dirty power, and heavy as a boat anchor. This one packs a highspeed inverter core that spits out clean, stable electricity (pure sine wave, less than 3% distortion). Your $3000 welder or your home theater won’t twitch. And because it’s an inverter, it sips fuel when you’re not hammering it – ECO mode makes 8KW surprisingly economical.
Light enough to move, tough enough to abuse
The open frame isn’t just for cooling – it’s for keeping the weight down. You can still slide it into a truck bed alone. A builtin folding handle and neverflat wheels turn a chore into a roll. Take it to the job site Monday, park it by the RV Wednesday, and have it ready for storm season all year.
Start it like your car
Forget the “snap the rope 15 times” dance. Electric start is standard – battery included. Press, crank, work. There’s also a recoil puller if the battery decides to nap. Lowoil shutdown keeps you from killing it by accident.
What can you actually run?
Construction: Large compressor, chop saw, concrete vibrator, site lights, battery chargers.
Home backup: 3-4 ton AC, sump pump, freezer, microwave, entertainment system – simultaneously.
RV / tailgating: Two rooftop ACs, induction cooktop, electric grill, and margarita machine.
Farm: Grain auger, pressure washer, well pump, heat lamp for the barn.
Quiet enough. Compliant enough.
It’s an open frame, so it’s not “library quiet.” But you’ll be surprised – the muffler and inverter tuning keep it below typical construction generators. EPA certified, so no issues with state regulations.
Bottom line
If you’re tired of underpowered “portable” generators that weigh a ton, or overpriced quiet boxes that can’t start a circular saw, this United Power 8KW is your honest answer. Big power, clean output, and a frame you can actually move.
| SPECIFICATIONS | |||
| Quiet Inverter Generator | IG8000E | ||
| Frequency(Hz) | 50 | ||
| AC Output Voltage(V) | 220 | 230 | 240 |
| Rated AC Output(W) | 7000 | ||
| Max. AC Output(W) | 7500 | ||
| Certificate | EURO-V CE RoHS | ||
| AC Output Amperage(A) | 31.8 | 30.4 | 29.2 |
| Power Factor | 1.0 | ||
| DC Voltage / DC Current | 8.3A/12V-16V(3600rpm) | ||
| Fuel Type | Gasoline | ||
| Fuel Tank Capacity(L) | 20L | ||
| Runtime @25% Load (Gas) | Up to 8 Hour | ||
| Net Weight/Gross Weight(kg) | 65 / 68 | ||
| Unit Dim( L x W x H )(mm) | 605 x 510 x 540 | ||
| Packing Dim( L x W x H )(mm) | 615 x 520 x 555 | ||
| 20/40/40HQ ft Container Qty | 144 / 304 / 304 | ||
| Engine Type | Single Cylinder 419cc - 4 Stroke OHV | ||
| Lubrication Oil | SAE 10W-30 | ||
| Lubrication Oil Volume(L) | 1100ml | ||
| Starting System | Recoil / Electric | ||
| Low Oil Shutdown | Yes | ||
| Engine RPM | Variable / 2600-3600rpm | ||
| Spark Plug | F6RTC | ||
| THD | <3%<> | ||
| Alternator Type | Digital Permanent Magnet | ||
| Parallel Capable | Yes - Requires Parallel Kit Sold Separately | ||
(1x) Spark plug wrench
(1x) Owner’s manual
