GG8300E
5800/6200W open-frame inverter generator
LEARN MOREWhen the job-site needs sustained power for a rotary hammer, or when a blackout hits your home – the United Power 5800/6200W open‑frame inverter generator gives you true heavy‑duty freedom in a surprisingly lightweight package.
You might think: a generator this powerful must be a beast to move. Not anymore. The open‑frame design uses reinforced steel tubing that maintains rigidity while shedding unnecessary weight – one person can easily pull, push, or lift it onto a pickup truck. Move it between job sites with zero struggle, or roll it from the garage to the house entry without breaking a sweat.
Inverter Technology + High‑Speed Engine = Clean, Strong Power
A high‑speed 4‑stroke gas engine paired with an advanced inverter module delivers 6200W surge and 5800W rated output. That means you can run simultaneously:
At home – mid‑size central AC, refrigerator, microwave, TV, lights, water pump, computer, security system.
On the job – rotary hammer, table saw, angle grinder, air compressor, small welder, lighting tower. Unlike traditional open‑frame generators, this inverter unit outputs steady voltage and frequency with very low distortion – safe for laptops, smart appliances, and the sensitive circuit boards in modern power tools.
Electric Start – Push and Go
A dedicated electric start button is built into the control panel, powered by a pre‑installed battery. Cold morning, wet hands, or after a long day – just push and the engine starts smoothly. A backup recoil pull cord is also provided for total reliability.
Built for Long Running Hours
The open frame offers two big advantages: 1) Far better heat dissipation than closed‑case units – perfect for all‑day construction work; 2) Easy maintenance – air filter, spark plug, and oil fill are right there. Oversized fuel tank plus ECO mode gives 6‑8 hours of run time at rated load, even longer at half load. Low‑oil shutdown protects the engine automatically.
Compliant, Quiet (for an open frame), and Ready to Work
Even as an open‑frame design, the muffler and airflow path are optimized to keep noise at reasonable levels – no neighborhood complaints. EPA‑certified, so it meets strict emission regulations across the US.
Where Will You Use It?
Home backup – Hurricanes, ice storms, grid failures – keep your essential appliances running.
Job sites – Remote locations, rough‑ins, outdoor builds – lightweight frame means you’ll actually take it where the work is.
Farm / ranch – Run water pumps, feed grinders, electric fencing – temporary power wherever you need it.
From a dark house after a storm to the noisy chaos of a construction site, the United Power lightweight high‑output inverter generator is the personal power plant you can actually carry.
Note: Add oil and gasoline before first use. Always operate outdoors in a well‑ventilated area, away from windows and doors. Please read the user manual carefully before starting.
Let me know if you need a shorter version or any specific adjustment for your store layout.
| SPECIFICATIONS | |||||
| Quiet Inverter Generator | IG7000FE | ||||
| Frequency(Hz) | 50 | 60 | |||
| AC Output Voltage(V) | 220 | 230 | 240 | 110/220 | 120/240 |
| Rated AC Output(W) | 5500 | ||||
| Max. AC Output(W) | 6000 | ||||
| Certificate | EURO-V CE RoHS | EPA | |||
| AC Output Amperage(A) | 25.0 | 23.9 | 22.9 | 25.0 | 22.9 |
| Power Factor | 1.0 | ||||
| DC Voltage / DC Current | 8.3A/12V-16V(3600rpm) | ||||
| Fuel Type | Gasoline | ||||
| Fuel Tank Capacity(L) | 15L | ||||
| Runtime @25% Load (Gas) | Up to 9 Hour | ||||
| Net Weight/Gross Weight(kg) | 48 / 52 | ||||
| Unit Dim( L x W x H )(mm) | 610 x 450 x 465 | ||||
| Packing Dim( L x W x H )(mm) | 640 x 480 x 500 | ||||
| 20/40/40HQ ft Container Qty | 168 / 336 / 420 | ||||
| Engine Type | UP182A Single Cylinder 321cc - 4 Stroke OHV | ||||
| Lubrication Oil | SAE 10W-30 | ||||
| Lubrication Oil Volume(L) | 1100ml | ||||
| Starting System | Recoil / Electric | ||||
| Low Oil Shutdown | Yes | ||||
| Engine RPM | Variable / 2600-3600rpm | ||||
| Spark Plug | F6RTC | ||||
| THD | <3%> | ||||
| Alternator Type | Permanent Magnet | ||||
| Parallel Capable | Yes - Requires Parallel Kit Sold Separately | ||||
(1x) Spark plug wrench
(1x) Owner’s manual
