DP100E

Ultra-Compact 2-Stroke Portable Gasoline Pump

  • Ultra-Light & Compact: 463×295×402 mm size, easy to carry for remote or off-grid use.
  • High Efficiency: 33.5cc 2-stroke air-cooled engine, delivers 300-400 L/min flow with 10-30m head.
  • Strong Self-Priming: 8m max suction head, reliable water intake from various sources. -
  • Versatile Use: Ideal for small-scale irrigation, garden watering, emergency drainage, and circulating systems.
  • Reliable Supply: 45-day delivery, 50,000 units annual capacity, Fujian factory quality assurance.
Send An Inquiry

PRODUCT DESCRIPTION

UNITED POWER DP100E is an ultra-compact 2-stroke gasoline-driven centrifugal pump, designed for maximum portability without sacrificing performance. Powered by a 33.5cc single-cylinder air-cooled engine, it delivers a flow rate of 300-400 L/min with a head range of 10-30m. The single-stage semi-open impeller and horizontal split pump casing ensure stable, efficient operation. With an 8m maximum suction head, it reliably draws water from diverse sources, making it ideal for small farm irrigation, garden maintenance, emergency flood control, and circulating water systems. Its lightweight, compact design (463×295×402 mm) and carton packaging enable easy transport to remote or hard-to-reach locations. With a 45-day delivery lead time and 50,000 units annual production capacity, it offers flexible procurement solutions. Manufactured in Fujian, China, under strict quality control, the DP100E is the perfect portable solution for everyday water transfer needs.

SPECIFICATIONS

ModelDP100E
Discharge Port Dia(mm)100(4in)
Rated Capacity(m3/h)106
Self-Priming Time(s/4m)180
Max. Head(m)26
Max. Suction Head(m)6
Dimension (L×W×H) (mm)645*475*610
Net weight/Gross weight(KG)73/76
20ft/40ft container Qty123/252
EngineUD186E
Engine TypeSingle-Cylinder, 4-Stroke, Air-Cooled; OHV Diesel Engine
Displacement Capacity(CC)418
Max. Output(HP/rpm)10/3600
Fuel Tank Capacity(L)5.4

INCLUDES

(1x) diesel water pump

(2x) Hose fitting

(2x) Hose adapter

(1x) Water filter

(2x) Sealing gasket

(3x) Hose clamp

(1x) Spark plug socket wrench

(1x) Owner’s manual

Seeking high-quality accessories for your machine? Submit an inquiry now!

Please provide the model type of your machine in your inquiry, and mention the keywords like chainsaw parts, brush cutter parts, sprayer/mist duster parts, leaf blower parts, hedge trimmer parts, water pump parts, generator parts, engine parts, lawn mower parts, etc.

FAQ

Here are questions frequently asked by customers. However, when the FAQ doesn’t answer your questions, you can send us a message to ask.

We are the manufacturer. Meanwhile, we have our own factory.
Our factory is in Fuzhou City, Fujian Province, China. It’s around 4 hour by express train or 2 hour by plane from Guangzhou to our city. Especially, our city has own sea port, Mawei port and Jiangyin port.
Ordinarily, it costs 20-25 workdays for 2x40ft containers. Additionally,the sample order can be finished in 5 days under standard type.
In general, payment≤2500 USD,100% in advance.
Besides, payment ≥ 2500 USD, 30% T/T in advance, balance against BL copy.
We strictly operate full QC process, such as incoming inspection, process inspection and final inspection. In other word, each product must be tested in production line before shipping.
