DHP50E
Electric Start High Lift Diesel Water Pump
- High Pressure Diesel Power: Max head of 50-80m, flow rate of 300-400 L/min, 305cc diesel engine (6.7 HP/3600 RPM) for high-lift performance.
- Robust & Convenient: Air-cooled diesel engine, single-stage semi-open impeller, horizontal split pump casing for durability and easy maintenance.
- Stable Water Transfer: 5m maximum suction head, 50mm discharge port, optimized for clean water, irrigation, and circulating pump applications.
- Easy Operation & Transport: Compact design, carton packaging, and diesel power for reliable, low-fuel-consumption use in remote or off-grid locations.
- Reliable Supply: 192pcs MOQ, 45-day delivery, 50,000 units annual capacity, Fujian factory quality assurance.
PRODUCT DESCRIPTION
UNITED POWER DHP50E is a high-pressure diesel-driven centrifugal pump, designed for efficient high-lift water transfer in demanding environments. Powered by a 305cc air-cooled diesel engine delivering 6.7 HP at 3600 RPM, it achieves a max head of 50-80m and flow rate of 300-400 L/min. The single-stage semi-open impeller and horizontal split pump casing ensure reliable performance and simplified maintenance. With a 5m maximum suction head and 50mm discharge port, it excels at clean water transfer, making it ideal for high-lift agricultural irrigation, remote water supply, and industrial circulating systems. Compact dimensions (557×470×547 mm) and carton packaging enable easy transport and installation. With a 192pcs MOQ, 45-day delivery lead time, and 50,000 units annual production capacity, it offers flexible procurement solutions. Manufactured in Fujian, China, under strict quality control, the DHP50E is a durable, cost-effective choice for off-grid or high-lift pumping applications.
SPECIFICATIONS
| Model | DHP50E |
| Discharge Port Dia(mm) | 50(2in) |
| Rated Capacity(m3/h) | 25 |
| Self-Priming Time(s/4m) | 60 |
| Max. Head(m) | 52 |
| Max. Suction Head(m) | 5 |
| Dimension (L×W×H) (mm) | 540*455*525 |
| Net weight/Gross weight(KG) | 53/56 |
| 20ft/40ft container Qty | 192/384 |
| Engine | UD178E |
| Engine Type | Single-Cylinder, 4-Stroke, Air-Cooled; OHV Diesel Engine |
| Displacement Capacity(CC) | 296 |
| Max. Output（HP/rpm) | 6.7/3600 |
| Fuel Tank Capacity(L) | 3.3 |
INCLUDES
(1x) Spark plug wrench
(1x) Owner’s manual
