DHP40E

High Pressure 50–80m Diesel Water Pump

High Pressure Performance: Max head of 50-80m, flow rate of 300-400 L/min, diesel-powered for strong, consistent pressure in high-lift applications.
Diesel Power & Convenience: 296cc diesel engine (6.7 HP/3600 RPM) with electric start, air-cooled design for reliable, low-fuel-consumption operation.
Reliable Water Intake: 5m maximum suction head, 40mm discharge port, single-stage semi-open impeller for stable clean water transfer.
Durable & Low-Maintenance: Horizontal split pump casing, semi-open impeller, built for long service life with minimal upkeep.
Flexible Supply: 192pcs MOQ, 45-day delivery, 50,000 units annual capacity, Fujian factory quality assurance.

Send An Inquiry

PRODUCT DESCRIPTION SPECIFICATIONS INCLUDES INQUIRY

PRODUCT DESCRIPTION

UNITED POWER DHP40E is a high-pressure diesel-driven centrifugal pump, purpose-built for high-lift water transfer applications. Powered by a 296cc air-cooled diesel engine with electric start, it delivers 6.7 HP at 3600 RPM, achieving a max head of 50-80m and flow rate of 300-400 L/min. Its single-stage semi-open impeller and horizontal split pump casing ensure stable performance and easy maintenance. With a 5m maximum suction head and 40mm discharge port, it reliably handles clean water transfer, making it ideal for high-lift irrigation, long-distance water supply, and industrial circulating systems. Compact dimensions (557×470×547 mm) and carton packaging simplify transport and installation. With a 192pcs MOQ, 45-day delivery lead time, and 50,000 units annual production capacity, it offers flexible procurement options. Manufactured in Fujian, China, under strict quality control, the DHP40E is a robust, cost-effective solution for demanding high-pressure pumping needs.

SPECIFICATIONS

Model	DHP40E
Discharge Port Dia(mm)	40(1.5in)
Rated Capacity(m3/h)	18
Self-Priming Time(s/4m)	65
Max. Head(m)	55
Max. Suction Head(m)	5
Dimension (L×W×H) (mm)	540455525
Net weight/Gross weight(KG)	42/45
20ft/40ft container Qty	192/384
Engine	UD178E
Engine Type	Single-Cylinder, 4-Stroke, Air-Cooled; OHV Diesel Engine
Displacement Capacity(CC)	296
Max. Output（HP/rpm)	6.7/3600
Fuel Tank Capacity(L)	3.3

INCLUDES

(1x) Spark plug wrench

(1x) Owner’s manual

Please provide the model type of your machine in your inquiry, and mention the keywords like chainsaw parts, brush cutter parts, sprayer/mist duster parts, leaf blower parts, hedge trimmer parts, water pump parts, generator parts, engine parts, lawn mower parts, etc.
