DHP40E
High Pressure 50–80m Diesel Water Pump
- High Pressure Performance: Max head of 50-80m, flow rate of 300-400 L/min, diesel-powered for strong, consistent pressure in high-lift applications.
- Diesel Power & Convenience: 296cc diesel engine (6.7 HP/3600 RPM) with electric start, air-cooled design for reliable, low-fuel-consumption operation.
- Reliable Water Intake: 5m maximum suction head, 40mm discharge port, single-stage semi-open impeller for stable clean water transfer.
- Durable & Low-Maintenance: Horizontal split pump casing, semi-open impeller, built for long service life with minimal upkeep.
- Flexible Supply: 192pcs MOQ, 45-day delivery, 50,000 units annual capacity, Fujian factory quality assurance.
PRODUCT DESCRIPTION
UNITED POWER DHP40E is a high-pressure diesel-driven centrifugal pump, purpose-built for high-lift water transfer applications. Powered by a 296cc air-cooled diesel engine with electric start, it delivers 6.7 HP at 3600 RPM, achieving a max head of 50-80m and flow rate of 300-400 L/min. Its single-stage semi-open impeller and horizontal split pump casing ensure stable performance and easy maintenance. With a 5m maximum suction head and 40mm discharge port, it reliably handles clean water transfer, making it ideal for high-lift irrigation, long-distance water supply, and industrial circulating systems. Compact dimensions (557×470×547 mm) and carton packaging simplify transport and installation. With a 192pcs MOQ, 45-day delivery lead time, and 50,000 units annual production capacity, it offers flexible procurement options. Manufactured in Fujian, China, under strict quality control, the DHP40E is a robust, cost-effective solution for demanding high-pressure pumping needs.
SPECIFICATIONS
| Model | DHP40E |
| Discharge Port Dia(mm) | 40(1.5in) |
| Rated Capacity(m3/h) | 18 |
| Self-Priming Time(s/4m) | 65 |
| Max. Head(m) | 55 |
| Max. Suction Head(m) | 5 |
| Dimension (L×W×H) (mm) | 540*455*525 |
| Net weight/Gross weight(KG) | 42/45 |
| 20ft/40ft container Qty | 192/384 |
| Engine | UD178E |
| Engine Type | Single-Cylinder, 4-Stroke, Air-Cooled; OHV Diesel Engine |
| Displacement Capacity(CC) | 296 |
| Max. Output（HP/rpm) | 6.7/3600 |
| Fuel Tank Capacity(L) | 3.3 |
INCLUDES
(1x) Spark plug wrench
(1x) Owner’s manual
