IG4500
United Power
| SPECIFICATIONS | ||
| Quiet Inverter Generator | IG4500 | |
| Frequency(Hz) | 60 | |
| AC Output Voltage(V) | 110 | 120 |
| Rated AC Output(W) | 3500 | |
| Max. AC Output(W) | 3800 | |
| Certificate | EPA | |
| AC Output Amperage(A) | 31.8 | 29.2 |
| Power Factor | 1.0 | |
| DC Voltage / DC Current | 8.3A/12V-16V(3600rpm) | |
| Noise(dB/4m) | ||
| Fuel Type | Gasoline | |
| Fuel Tank Capacity(L) | 10L | |
| Runtime @25% Load (Gas) | Up to 6 Hour | |
| Net Weight/Gross Weight(kg) | 28.5/30.7 | |
| Unit Dim( L x W x H )(mm) | 492 x 402 x 477 | |
| Packing Dim( L x W x H )(mm) | 540 x 450 x 515 | |
| 20/40/40HQ ft Container Qty | 200 / 428 / 428 | |
| Engine Type | Single Cylinder 223cc - 4 Stroke OHV | |
| Lubrication Oil | SAE 10W-30 | |
| Lubrication Oil Volume(L) | 600ml | |
| Starting System | Recoil | |
| Low Oil Shutdown | Yes | |
| Engine RPM | Variable / 2600-3600rpm | |
| Spark Plug | F6RTC | |
| THD | <3% | |
| Alternator Type | Digital Permanent Magnet | |
| Parallel Capable | Yes - Requires Parallel Kit Sold Separately | |
